HFT Single Step Multiple Pump Drives Gearboxes For Motorcycle Customized Request

Model NO. : HFT

Assembly : Easy Assembly

Design : Robust and Modular Design

Ground Tooth : Notchless Ground Tooth Root

Delivery : Fast Delivery

Load Capacity : Higher Load Capacity

Output Torque : Higher Output Torque

Transport Package : Wooden Boxes

Trademark : Elite

Origin : China

HS Code : 8483402090

Supply Ability : 200/Month

Application : Motor, Motorcycle, Machinery, Agricultural Machinery

Function : Change Drive Torque, Speed Changing, Speed Reduction

Hardness : Hardened Tooth Surface

Step : Single-Step

Type : Planetary Gear Box

Warranty : 18 Months

Customization : Available | Customized Request

Contact Now

Pump Drive is a transfer gearbox used for the connection of Diesel Engine and Hydraulic Pumps. We are making a wide variety of gear ratios, including speed-increasing and speed-reducing options. Modular design options include a flexible coupling, rubber block drive, or clutch to match your SAE engine flywheel dimensions. Independent mounting is an option, direct or with a clutch. We are also making standard and specialized SAE and DIN adaptor kits for special needs.

Features:

High Strength Aluminum Aloy housing.
Hardened Shaved gears.
Ball bearings.
Case hardened shafts.
Viton seals on input shaft.
Output rotation opposite the direction of input rotation.
Gear ratios identical on all outputs.

Specifications:

Model	2 pump drives				3 pump drives				4 pump drives
Parameter	HFT190-2N	HFT400-2N	HFT530-2N	HFT700-2N	HFT280-3N	HFT400-3N	HFT530-3N	HFT700-3N	HFT280-4N	HFT530-4N	HFT700-4N
Max. Input power (KW)	190	400	530	700	280	400	530	700	280	530	700
Max. Output power per pump pad (KW)	110	210	270	360	150	210	280	360	150	280	360
Max. Output torque per pump pad (Nm)	500	1050	1500	1900	900	1050	1500	1900	900	1500	1900
Max. Input speed (RPM)	4000	3500	3500	3000	3800	3500	3500	3000	3800	3500	3000
Max. Output speed (RPM)	4000	3500	3500	3000	3800	3500	3500	3000	3800	3500	3000
Transmission ratio	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486	0.512-1.486
Mount size of Prime mover	SAE #3 #4 etc.	SAE #2 #3 etc.	SAE #1 #2 #3 etc.	SAE #0 #1 #2 etc.	SAE #3 #4 etc.	SAE #2 #3 etc.	SAE #1 #2 #3 etc.	SAE #0 #1 #2etc.	SAE #3 #4 etc.	SAE #1 #2 #3 etc.	SAE #1 #2 etc.
Port size of Single pump	SAE A,B,C flange etc.	SAE A,B,C,D flange etc.	SAE B,C,D,E flange etc.	SAE C,D,E flange etc.	SAE A,B,C flange etc.	SAE A,B,C,D flange etc.	SAE B,C,D,E flange etc.	SAE C,D,E flange etc.	SAE A,B,C flange etc.	SAE B,C,D,E flange etc.	SAE B C,D flange etc.
Housing material	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron	Cast iron

HFT Single Step Multiple Pump Drives Gearboxes For Motorcycle Customized Request

In conclusion, ELITE Hydraulic offers quality, value, and professional power transmission solutions that cater to a wide variety of industries. With their expertise, experience, and commitment to customer satisfaction, you can be sure that you're in safe hands when working with them. Whether you need travel gearbox, electrical drive, travel drive,slew gearbox,winche gearbox,cutter gearbox,truck mixer gearbox,twin shaft mixer or other hydraulic transmission solutions, you can trust ELITE Hydraulic to provide you with the best possible solutions. Contact them today to learn more about their power transmission products and services.
